CP247
Gallery
BrandKAMOKA
MPN103136
OE refs5
SKU0185-103136
GTIN / EAN5901779868691

Similar products

Customers also bought

Details

SpecificationValue
BrandKAMOKA
CategoryBrake rotor
Fitting PositionRear Axle
Height [mm]73 mm
Brake Disc Thickness [mm]9 mm
Outer Diameter [mm]249 mm
Centering Diameter [mm]56 mm
Bolt Hole Circle Ø [mm]108 mm

OE numbers (5)

Search by this OE number to find compatible parts

Where this part fits

Original-fit position for OE 424966.

PART — Others
OthersPosition main

About this product

KAMOKA brake disc (103136) is precision-machined from high-grade grey cast iron for uniform heat dissipation and resistance to thermal cracking under heavy braking. Key dimensional data — for OE number: 1609249980, Fitting Position: Rear Axle, Height [mm]: 73 mm, Brake Disc Type: Steel — ensures the rotor geometry meets OEM tolerances for run-out, thickness, and parallelism right out of the box. Compatible with CITROËN, DS, PEUGEOT vehicles; the hub-centric bore and bolt-circle pattern match the original specification exactly. Direct replacement for OE references: 051419B, 0 986 479 022, 1609249980, 1619238780 and 39 more. KAMOKA rotors are checked for surface hardness and dynamic balance before dispatch, keeping braking distances predictable throughout the service life of the disc. Brake discs generally last 50,000–70,000 miles, though this varies with driving habits, terrain, and pad compound — heavy urban driving or towing shortens disc life considerably. Warning signs of worn discs include visible scoring or lip formation on the friction surface, vibration through the steering wheel under braking, and a persistent grinding noise even with new pads fitted. Disc replacement is an intermediate DIY task; you will need a torque wrench, a breaker bar (some hub-to-disc retaining screws seize over time), and a jack with axle stands — budget 1–2 hours per axle. When selecting brake discs, check that the disc type (vented or solid) matches the original, and look for a protective anti-corrosion coating on the hub and non-friction surfaces to prevent rust jacking. Always replace discs in pairs (both sides of the same axle) to maintain even braking balance, and bed in new discs with the manufacturer's recommended gentle-braking procedure for the first 200 miles. Every part is dispatched with tracked delivery and a 14-day money-back guarantee with hassle-free returns.

Brake rotor buying guide

Why replace this part?

Brake discs work together with brake pads to bring your vehicle to a stop. Over time, discs wear down, develop grooves, or can warp from heat. Worn or warped discs reduce braking efficiency and can cause dangerous vibrations at speed.

Signs you need a replacement

  • Pulsating brake pedal
  • visible grooves or scoring on the disc surface
  • vibration during braking
  • grinding noise even with new pads
  • disc thickness below minimum specification

When to replace

Every 50,000–80,000 miles. Always measure disc thickness during pad changes — most discs have a minimum thickness stamped on the hub.

Installation difficulty:Moderate — requires basic tools and mechanical knowledge

Suitable cars

Equivalent products (39)

Show all 39 OE numbers
A.B.S.18130
A.B.S.18130C
ASHIKA61-00-0607
AUTLOGBS6014
BENDIX051419B
BOSCH0 986 479 022
JAPANPARTSDP-0607
JAPKO610607
MASTER-SPORT GERMANY24010901711PR-PCS-MS
MASTER-SPORT GERMANY24112523881-PCS-MS
MAXGEAR19-1280
MAXGEAR19-1969
MAXGEAR19-1969SPORT
METELLI23-1394
METZGER AUTOTEILE6110725
METZGER AUTOTEILE6111050
MINTEXMDC2031
ProfiPower3B2173
PROFIT3B2173
PROTECHNICPRD5290B
QUINTON HAZELLBDC5597
RIDEX82B0656
RIDEX82B0745
StarkSKBD-0022806
StarkSKBD-0022895
SWAG62 93 2783
TOMEX BrakesTX 73-611

Brake rotor KAMOKA 103136compatible car models

Car modelsCITROËN: C4 Coupe (LA), C4 II Hatchback Van (NC), C4 II (NC), C4 II Saloon (NC), C4 I (LC), DS4 (NX); DS: DS 4 / DS 4 CROSSBACK (NX); PEUGEOT: 308 CC (4B), 308 I (4A, 4C), 308 II (LB, LP, LW, LH, L3), 308 SW I (4E, 4H), 308 SW I Estate Van (4E)
Engines1.4 16V; 1.6 BlueHDi; 1.2 THP 110 (NCHNZ6, NCHNV6); 1.6; 1.6 16V; 1.2 THP 130; 1.2 THP 130 (NXHNYM); 1.6 THP 163; 1.6 HDi
Year of manufacture2004-2021
Manufacturer article number (MPN)103136
OE part numbers1609249980, 1619238780, 424965, 424966, 9651556880
Compatibility check

Loading vehicle data…

Please wait while we load vehicle compatibility information.
Description and what's included

KAMOKA 103136 Brake rotor. Bolt Hole Circle Ø [mm]: 108 mm. Brake Disc Thickness [mm]: 9 mm. Brake Disc Type: 1. Centering Diameter [mm]: 56 mm. Fitting Position: HA. for OE number: 1609249980. Height [mm]: 73 mm. Number of Holes: 4

What's included:
  • 1x Brake disc
Shipping, returns, warranty

Free UK delivery on orders over £99.00. Tracked standard shipping.

  • Standard delivery: 5–9 business days
  • Order before 5pm — ships the next working day
  • Free returns within 14 days
  • All parts backed by manufacturer warranty

Warranty: 12-month manufacturer warranty on all parts. 14-day money-back guarantee if the part doesn't fit your vehicle.

Frequently Asked Questions

Is this Brake rotor compatible with my car?

This Brake rotor fits CITROËN, DS, PEUGEOT vehicles. Use the vehicle selector at the top of the page to check exact compatibility — enter your car's make, model, and engine for a confirmed fitment match. All fitment data is verified through TecDoc.

What specifications does this KAMOKA Brake rotor have?

This KAMOKA Brake rotor has the following specifications: for OE number: 1609249980; Fitting Position: HA; Height [mm]: 73 mm; Brake Disc Type: 1; Brake Disc Thickness [mm]: 9 mm; Outer Diameter [mm]: 249 mm. Check the full specifications table above for complete details.

What OE part numbers does this Brake rotor replace?

This Brake rotor replaces OE part numbers: 1609249980, 1619238780, 424965, 424966, 9651556880. Cross-reference these numbers with your vehicle's original part number to confirm compatibility.

How much does a Brake rotor cost?

This KAMOKA Brake rotor is available for £44.99. Brake rotor prices vary depending on brand, specifications, and vehicle compatibility. KAMOKA parts offer a balance of quality and value, backed by our 14-day money-back guarantee.

How do I know when to replace my Brake rotor?

Watch for pulsating brake pedal, visible grooves or scoring on the disc surface, vibration during braking, or a grinding noise. Brake discs typically last 50,000-80,000 miles but should be measured for minimum thickness during pad changes.

What tools do I need to replace a Brake rotor?

Tools needed: floor jack and axle stands, lug wrench, 7mm hex / Torx caliper bolt socket, pry bar or disc puller, wire brush, brake cleaner, copper grease, torque wrench (wheel bolts to manufacturer spec). Difficulty: Moderate DIY. Safety warning: Do not drive the vehicle until both discs on the same axle are replaced and the brakes have been bedded in. Brake dust may contain harmful particles -- wear a dust mask.

Can I use this part as a replacement for OE 1609249980?

Yes, this KAMOKA Brake rotor is a direct replacement for OE part number 1609249980. It is manufactured to meet or exceed original equipment specifications, ensuring proper fitment and performance. All cross-reference data is verified through TecDoc.
