BrandABAKUS
MPN231-03-080
OE refs2
SKU4657-231-03-080

Similar products

Customers also bought

Details

SpecificationValue
BrandABAKUS
MPN231-03-080
CategoryBrake rotor
Test MarkECE R90
Height [mm]42 mm
Brake Disc Thickness [mm]25 mm
Outer Diameter [mm]280 mm
Centering Diameter [mm]60 mm
Bolt Hole Circle Ø [mm]100 mm

OE numbers (2)

Search by this OE number to find compatible parts

Where this part fits

Original-fit position for OE 569006. The red ring marks where this part installs on the vehicle.

SET,DISC,260 X 24 MM,FRONT BRAKE,VENTILATED  (PRODUCTION NO. 9127967) — Opel  CORSA-C ( 2001 - ) — J BRAKES › 17.FRONT BRAKE DISC AND SHIELD
Opel CORSA-C ( 2001 - ) · J BRAKES › 17.FRONT BRAKE DISC AND SHIELDPosition 3X

About this product

ABAKUS brake disc (231-03-080) is precision-machined from high-grade grey cast iron for uniform heat dissipation and resistance to thermal cracking under heavy braking. Key dimensional data — Test Mark: ECE R90, Height [mm]: 42 mm, Required quantity: Aluminium, Brake Disc Type: Carbon — ensures the rotor geometry meets OEM tolerances for run-out, thickness, and parallelism right out of the box. Compatible with OPEL vehicles; the hub-centric bore and bolt-circle pattern match the original specification exactly. Direct replacement for OE references: 0 986 479 B68, 0 986 479 S55, 09.9159.10, 09.9159.11 and 53 more. ABAKUS rotors are checked for surface hardness and dynamic balance before dispatch, keeping braking distances predictable throughout the service life of the disc. Brake discs generally last 50,000–70,000 miles, though this varies with driving habits, terrain, and pad compound — heavy urban driving or towing shortens disc life considerably. Warning signs of worn discs include visible scoring or lip formation on the friction surface, vibration through the steering wheel under braking, and a persistent grinding noise even with new pads fitted. Disc replacement is an intermediate DIY task; you will need a torque wrench, a breaker bar (some hub-to-disc retaining screws seize over time), and a jack with axle stands — budget 1–2 hours per axle. When selecting brake discs, check that the disc type (vented or solid) matches the original, and look for a protective anti-corrosion coating on the hub and non-friction surfaces to prevent rust jacking. Always replace discs in pairs (both sides of the same axle) to maintain even braking balance, and bed in new discs with the manufacturer's recommended gentle-braking procedure for the first 200 miles. Every part is dispatched with tracked delivery and a 14-day money-back guarantee with hassle-free returns.

Brake rotor buying guide

Why replace this part?

Brake discs work together with brake pads to bring your vehicle to a stop. Over time, discs wear down, develop grooves, or can warp from heat. Worn or warped discs reduce braking efficiency and can cause dangerous vibrations at speed.

Signs you need a replacement

  • Pulsating brake pedal
  • visible grooves or scoring on the disc surface
  • vibration during braking
  • grinding noise even with new pads
  • disc thickness below minimum specification

When to replace

Every 50,000–80,000 miles. Always measure disc thickness during pad changes — most discs have a minimum thickness stamped on the hub.

Installation difficulty:Moderate — requires basic tools and mechanical knowledge

Suitable cars

Equivalent products (54)

Show all 54 OE numbers
BARUMBAR25148
BENDIX562278B
BREMBO09.9159.10
CAR142.035
CIFAM800-800
DELPHIBG3933
FERODODDF1236
FERODODDF1236C-1
FTEBS5455
GALFERB1.G225-0148.1
GALFERG2125148
GRAFDF29800
HART229060
HELLA PAGID8DD 355 110-241
HELLA PAGID8DD 355 110-251
JURID562278J
KAMOKA103254
LPRO1006V£54.99
MAXGEAR19-1065
MAXGEAR19-1065MAX
MAXGEAR19-1314
MAXGEAR19-1314MAX
MAXGEAR19-1314SPORT
METELLI23-0800
METELLI23-0800C
MINTEXMDC1673
NK203652
PAGID54246
PAGID54246PRO
PEX14.0817
PILENGAV379
QUINTON HAZELLBDC5455
QUINTON HAZELLBSF5455
ROADHOUSE6685.10
ROULUNDS BRAKINGWD00905
TEXTAR92124600
TEXTAR98200 1246 0 1
TEXTAR98200 1246 0 1 PRO
TRWDF4318
TRWDF4426£35.99
ZIMMERMANN430.2600.00
ZIMMERMANN430.2600.50

Brake rotor ABAKUS 231-03-080compatible car models

Car modelsOPEL: COMBO Box Body/MPV, COMBO Box Body/MPV (71), COMBO Tour, MERIVA A MPV (X03)
Engines1.3 CDTI 16V; 1.4 16V; 1.3 CDTI (E75)
Year of manufacture1994-2011
Manufacturer article number (MPN)231-03-080
OE part numbers5 69 006, 93175376
Compatibility check

Loading vehicle data…

Please wait while we load vehicle compatibility information.
Description and what's included

ABAKUS 231-03-080 LORO. Bolt Hole Circle Ø [mm]: 100 mm. Brake Disc Thickness [mm]: 25 mm. Brake Disc Type: 8. Centering Diameter [mm]: 60 mm. Height [mm]: 42 mm. Number of Holes: 4. Outer Diameter [mm]: 280 mm. Required quantity: 2

What's included:
  • 1x Brake disc
Shipping, returns, warranty

Free UK delivery on orders over £99.00. Tracked standard shipping.

  • Standard delivery: 5–9 business days
  • Order before 5pm — ships the next working day
  • Free returns within 14 days
  • All parts backed by manufacturer warranty

Warranty: 12-month manufacturer warranty on all parts. 14-day money-back guarantee if the part doesn't fit your vehicle.

Frequently Asked Questions

Is this Brake rotor compatible with my car?

This Brake rotor fits OPEL vehicles. Use the vehicle selector at the top of the page to check exact compatibility — enter your car's make, model, and engine for a confirmed fitment match. All fitment data is verified through TecDoc.

What specifications does this ABAKUS Brake rotor have?

This ABAKUS Brake rotor has the following specifications: Test Mark: ECE R90; Height [mm]: 42 mm; Required quantity: 2; Brake Disc Type: 8; Brake Disc Thickness [mm]: 25 mm; Outer Diameter [mm]: 280 mm. Check the full specifications table above for complete details.

What OE part numbers does this Brake rotor replace?

This Brake rotor replaces OE part numbers: 5 69 006, 93175376. Cross-reference these numbers with your vehicle's original part number to confirm compatibility.

How much does a Brake rotor cost?

This ABAKUS Brake rotor is available for £28.99. Brake rotor prices vary depending on brand, specifications, and vehicle compatibility. ABAKUS parts offer a balance of quality and value, backed by our 14-day money-back guarantee.

How do I know when to replace my Brake rotor?

Watch for pulsating brake pedal, visible grooves or scoring on the disc surface, vibration during braking, or a grinding noise. Brake discs typically last 50,000-80,000 miles but should be measured for minimum thickness during pad changes.

What tools do I need to replace a Brake rotor?

Tools needed: floor jack and axle stands, lug wrench, 7mm hex / Torx caliper bolt socket, pry bar or disc puller, wire brush, brake cleaner, copper grease, torque wrench (wheel bolts to manufacturer spec). Difficulty: Moderate DIY. Safety warning: Do not drive the vehicle until both discs on the same axle are replaced and the brakes have been bedded in. Brake dust may contain harmful particles -- wear a dust mask.

Can I use this part as a replacement for OE 5 69 006?

Yes, this ABAKUS Brake rotor is a direct replacement for OE part number 5 69 006. It is manufactured to meet or exceed original equipment specifications, ensuring proper fitment and performance. All cross-reference data is verified through TecDoc.
